POLITERM® BLU FEIN

ULTRA-LIGHTWEIGHT THERMALLY INSULATING AGGREGATE, PRE-COATED WITH E.I.A. ADDITIVE. BEAD Ø ≤ 2 MM

POLITERM® BLU FEIN is the fine-bead version (Ø ≤ 2 mm (≤ 3/32 in)) of POLITERM® BLU, for lightweight thermally insulating subfloors and screeds made on site with cement and water. The fine bead gives a more homogeneous and compact mix and a smoother surface, while still weighing as little as a tenth of a traditional subfloor.

It is made of EPS beads coated with E.I.A. additive: the additive makes the beads mix perfectly with cement, stops them floating and spreads them evenly through the mix, at low and high densities alike. The result is a lightweight concrete that does not settle, does not shrink and does not crack. It is the only RAL-certified aggregate. It is the only product that makes self-levelling lightweight thermally insulating mortars possible.

With the same product you obtain densities from formula 110 (about 130 kg/m³ (8.1 lb/ft³), λD 0.042 W/mK (0.29 BTU·in/(h·ft²·°F))) up to 1800 kg/m³ (112 lb/ft³) and 25 N/mm² (3,626 psi). It needs very little mixing water and dries quickly (about 1 day per cm).

It is mixed in a cement mixer or horizontal mixer and pumped with POLITERM® MACHINE, ISOLCAP MACHINE or screed pumps. Reaction to fire A2-s1,d0.

NOTE

Does not settle
No bleeding
Dimensionally stable
Non-shrink
No cracking
RAL certified

Closed-cell virgin EPS beads Ø ≤ 2 mm (≤ 3/32 in), coated with E.I.A. additive.
Formula 110: about 130 kg/m³ (8.1 lb/ft³), λD 0.042 W/mK (0.29 BTU·in/(h·ft²·°F)), compressive strength 0.528 N/mm² (77 psi), μ 5.1.
Achievable densities 130-1800 kg/m³ (8.1-112 lb/ft³).
λD: 0.0489 W/mK (0.34 BTU·in/(h·ft²·°F)) (150 kg/m³ mix) · 0.065 W/mK (0.45 BTU·in/(h·ft²·°F)) (250) · 0.079 W/mK (0.55 BTU·in/(h·ft²·°F)) (300) · 0.104 W/mK (0.72 BTU·in/(h·ft²·°F)) (500) · 0.176 W/mK (1.22 BTU·in/(h·ft²·°F)) (800) · 0.191 W/mK (1.32 BTU·in/(h·ft²·°F)) (1000).
Compressive strength: 0.59 N/mm² (86 psi) (150) · 0.83 N/mm² (120 psi) (250) · 1.61 N/mm² (234 psi) (300) · 2.24 N/mm² (325 psi) (500) · ≥ 5 N/mm² (≥ 725 psi) (800) · ≥ 12 N/mm² (≥ 1,740 psi) (1200) · ≥ 25 N/mm² (≥ 3,626 psi) (1800).
μ 5.9-14.0; specific heat 1.0 kJ/kgK.
ΔLw 14 dB (5 cm (2 in) formula 250 + 5 cm (2 in) screed) · 26 dB (7 cm (2 3/4 in) formula 300 + DBRED FONOTECH 5); L'nT,w 61 dB (formula 250, 11 cm (4 3/8 in)).
Reaction to fire A2-s1,d0; rot-proof.
Cement: Portland 32.5 CEM I or CEM II limestone. Application +5 to +35 °C (41 to 95 °F) (liquid antifreeze admixture allowed below +5 °C (41 °F)).
Minimum thickness on absorbent substrates 5 cm (2 in).
Yield: 2 bags of 420 L (111 US gal) or 5 bags of 170 L (44.9 US gal) per 1 m³ (35 ft³) (up to 350 kg/m³ (21.8 lb/ft³)).

PACKAGING

Subfloors on ground and pilotis floors, between floors, on roofs and on timber floors.
Single-layer screeds for directly glued floor coverings (see the POLITERM® BLU application manual).
Falls on terraces and flat roofs, also with direct laying of solvent-free waterproofing membranes.
Insulation of non-walkable attics and pitched roofs.
Vault infill, even at very high thicknesses.
Encapsulation of asbestos-cement roof sheets.
Fill beneath trafficable asphalt pavements.
Subfloors for industrial flooring.
