PROTHERM LIGHT®

PREMIXED, LIGHTWEIGHT, AND THERMALLY INSULATING PLASTER FOR FIRE PROTECTION

PROTHERM LIGHT® is the lightweight, thermally insulating pre-mixed plaster used to increase the fire resistance of structural elements – steel, reinforced and prestressed concrete, masonry and composite steel-concrete slabs – in residential, commercial and industrial buildings, new or existing, indoors and outdoors.

Made with EPS beads, hydraulic binders and special additives, it is non-combustible (class A1), lightweight (about 300 kg/m³ (18.7 lb/ft³)), breathable and water-repellent, with very good resistance to weathering. It has been tested to EN 13381 and has a European Technical Assessment ETA 18-1111: the classification reports are used to determine the coating thickness needed for the required fire resistance class.

It is sprayed with a plastering machine (PFT G4, G5 type), in a single coat up to 20 mm (13/16 in) or in several coats. Consumption is about 3 kg/m² per cm of thickness (1.56 lb/ft² per inch of thickness); surface drying in 24 hours. Available in white and grey.

NOTE

Class A1
Available in white and grey
For indoor and outdoor use

Density about 300 kg/m³ (18.7 lb/ft³); reaction to fire A1 (EN 13501-1).
Compressive strength 0.97 N/mm² (141 psi) (EN ISO 12390-3); flexural strength 0.35 N/mm² (51 psi) (EN ISO 12390-5).
Thermal conductivity λD 0.079 W/mK (0.55 BTU·in/(h·ft²·°F)); μ 9.
Surface drying 24 h (+20 °C (68 °F), natural ventilation).
ETA 18-1111 – tests EN 13381-3 (concrete), -4 (steel), -5 (composite slabs), -1 (horizontal membranes).
Consumption about 3 kg/m² per cm of thickness (1.56 lb/ft² per inch of thickness) (1 bag ≈ 6 m² (≈ 65 ft²) at 1 cm (13/32 in)).
18 kg (40 lb) bag; pallet of 44 bags. Machine application from +5 to +35 °C (41 to 95 °F).
